Industrial Grade Through Hole Slip Ring for UAV Camera Gimbal

1
MOQ
200-800USD
Price
Industrial Grade Through Hole Slip Ring for UAV Camera Gimbal
Features Gallery Product Description Chat Now
Features
Specifications
Rotating Speed: 0-3000 Rpm
Design Loop: 6
Dynamic Resistance Change: ≤10mΩ
Working Temperature: -45℃ ~ 60℃
Maximum Current: 1A
Shell Material: Stainless Steel+alluminum Alloy
Highlight:

industrial grade slip ring for UAV

,

through hole slip ring for gimbal

,

mini slip ring with warranty
Basic Infomation
Place of Origin: Shenzhen
Brand Name: SPR-ing
Model Number: SP018006
Payment & Shipping Terms
Packaging Details: Carton
Delivery Time: 1 week
Payment Terms: L/C,T/T
Supply Ability: 1000/month
Product Description
Industrial Grade Through Hole Slip Ring for UAV Camera Gimbal

The SP018006 mini electric slip ring is engineered for UAVs requiring 360° rotation with uninterrupted power and signal delivery. Featuring lightweight construction (<30g), stainless steel + aluminum housing, and IP51 protection, it ensures reliable operation under vibration and rotation.

Applications
  • UAV camera gimbals
  • Drone sensor modules
  • Aerial robotics
Technical Specifications
Electrical Specifications
Design Loop 6
Insulation Resistance 250MΩ/250V/DC
Current 1A
Dielectric Strength >250VAC/50Hz/60s
Dynamic Resistance Change Value ≤10mΩ
Mechanical Specifications
Rated Speed 0-3000 rpm
Working Life ≥100 hours (Storage life: ≥12 years)
Operating Temperature -45℃ to 60℃
Contact Material Gold-gold
Shell Material Stainless steel + aluminum alloy
Maximum Starting Torque 3m N.m
Weight <30g (excluding wire)
IP Grade IP51
Outline Drawing
Industrial Grade Through Hole Slip Ring for UAV Camera Gimbal 0
Technical Advantages
Core Friction Pair Technology: Gold metal contact technology ensures ultra-long service life
Integrated Casting Process: Concentricity between ring groove and bearing ≤ 0.01mm
Mirror Processing Technology: Contact surface smoothness reaches Ra0.02 for reliable contact
Precision Component Manufacturing: Dimensional tolerance <0.01mm, axial displacement <0.01mm
Advanced Brush Wire Modulation: Near-zero pressure brush design extends slip ring life by 1/3
High-Speed Capability: Maximum speed of 8000 revolutions per minute (with cooling system)
Extended Lifespan: Maximum operational life of up to 100 million revolutions
