Gold-Gold Contact 8 Circuits 1A Capsule Slip Ring for Medical Equipment

SP013008 Ultra Miniature Slip Ring is designed to provide uninterrupted electrical transmission between stationary and rotating structures. With 8 independent circuits, this compact rotary joint enables stable transmission of power, control signals, and communication data during 360° continuous rotation.

Manufactured using precision machining technology, the contact surface smoothness reaches Ra0.02, ensuring highly reliable contact and minimal wear. The advanced gold contact technology effectively reduces electrical noise and improves transmission quality in high-speed applications.

The lightweight aluminum alloy body offers excellent mechanical strength while maintaining compact dimensions and low weight below 20g. Suitable for industrial automation, UAVs, rotating LED systems, medical devices, and smart mechanical equipment.

Advantages:

• Compact capsule design
• Stable electrical performance
• Low torque operation
• High rotational reliability
• Long service life
• Customizable speed and lifespan

• Slip ring's core technology - friction pair technology: gold metal contact technology, ensuring ultra long service life
• Integrated casting process: Ensures concentricity between ring groove and bearing ≤ 0.01mm
• Mirror processing technology: Ensures slip ring contact surface smoothness reaches Ra0.02 for more reliable contact
• Precision component manufacturing process: Dimensional tolerance <0.01mm, axial displacement <0.01mm for high precision and stable performance
• Advanced brush wire modulation technology: Nearly zero pressure brush design and debugging process extends slip ring life by 1/3
• High speed capability: Maximum speed of 8000 revolutions per minute (with cooling system)
• Long lifespan: Maximum lifespan up to 100 million revolutions per minute

This high-speed electrical slip ring is widely used in applications requiring continuous 360° rotation with simultaneous power and signal transmission, including:

• Industrial automation equipment
• Robotics and robotic arms
• UAV gimbal systems
• Rotating surveillance cameras (PTZ cameras)
• Radar and antenna systems
• Test and measurement equipment
• Precision rotary platforms
• Medical imaging systems

• Experienced manufacturer with professional engineering team
• High precision manufacturing process
• Strict quality control system
• Custom slip ring solutions available
• Fast technical support and global delivery

A slip ring is used to transmit power, signals, or data between stationary and rotating parts in rotating equipment such as robotics, radar systems, and industrial automation machinery.

This slip ring supports rotational speeds up to 3000 RPM, making it suitable for high-speed rotating applications.

Slip rings are widely used in industrial automation, robotics, UAV systems, radar antennas, medical equipment, and rotating cameras.

Yes, the slip ring can be customized with different circuits, current ratings, sizes, and protection levels depending on the application.
