Electric Slip Ring Multi Circuits Rotary Joint For Mechanical Equipment

1
MOQ
200-800USD
Price
Electric Slip Ring Multi Circuits Rotary Joint For Mechanical Equipment
Features Gallery Product Description Chat Now
Features
Specifications
Rotating Speed: 0-1000 Rpm (1000-10000RPM Requires Customization)
Design Loop: 8
Dielectric Strength: >250VAC/50Hz/60s
Insulation Resistance: 250MΩ/250V/DC
Dynamic Resistance Change: ≤10mΩ
Working Temperature: -40℃ ~ 65℃
Maximum Current: 1A
Shell Material: Aluminum Alloy
Highlight:

Electric slip ring for mechanical equipment

,

Multi-circuit rotary joint slip ring

,

Mini slip ring with warranty
Basic Infomation
Place of Origin: Shenzhen
Brand Name: SPR-ing
Model Number: SP013008
Payment & Shipping Terms
Packaging Details: Carton
Delivery Time: 1 week
Payment Terms: L/C,T/T
Supply Ability: 1000/month
Product Description
Ultra Compact Slip Ring for Space-Limited Applications

The SP013008 Ultra Compact Slip Ring is designed for applications requiring stable power and signal transmission within extremely limited installation spaces. With an advanced gold-gold contact structure, this miniature rotary joint provides excellent conductivity, low electrical noise, and reliable long-term performance.

Its precision-engineered internal structure minimizes friction and improves operational stability during continuous 360° rotation. The lightweight aluminum alloy housing ensures strong mechanical durability while maintaining a total weight below 20g.

This compact slip ring is ideal for UAV systems, rotating sensors, compact robotic equipment, intelligent automation devices, and pan-tilt camera systems.

Main Features:

  • Ultra-small 8-circuit design
  • Stable signal and power transmission
  • Long operating life up to 10 million revolutions
  • Low torque and smooth rotation
  • High-speed customization support
  • Excellent durability and sealing performance
Technical Parameters
Electrical specifications
Design loop 1~8
Insulation resistance 250MΩ/250V/DC
Rated voltage/current 80VDC / 1A
Dielectric strength >250VAC/50Hz/60s
Dynamic resistance change value ≤10mΩ
Mechanical specifications
Rated speed 0-1000 rpm (1000-10000RPM requires customization)
Working life 10 million rpm (>10 million rpm requires customization)
Operating temperature -40℃ ~ 65℃
Operating humidity ≤80%
Contact material Gold-gold
Shell material Aluminum alloy
Weight <20g
IP grade IP51
Outline Drawing
Electric Slip Ring Multi Circuits Rotary Joint For Mechanical Equipment 0
Technical Advantages
  • Slip ring's core technology - friction pair technology: gold metal contact technology, ensuring ultra long service life
  • Integrated casting process: Ensures concentricity between ring groove and bearing ≤ 0.01mm
  • Mirror processing technology: Ensures slip ring contact surface smoothness reaches Ra0.02 for more reliable contact
  • Precision component manufacturing process: Dimensional tolerance <0.01mm, axial displacement <0.01mm for high precision and stable performance
  • Advanced brush wire modulation technology: Nearly zero pressure brush design and debugging process extends slip ring life by 1/3
  • High speed capability: Maximum speed of 8000 revolutions per minute (with cooling system)
  • Long lifespan: Maximum lifespan up to 100 million revolutions per minute
Application Scenarios

This high-speed electrical slip ring is widely used in applications requiring continuous 360° rotation with simultaneous power and signal transmission, including:

  • Industrial automation equipment
  • Robotics and robotic arms
  • UAV gimbal systems
  • Rotating surveillance cameras (PTZ cameras)
  • Radar and antenna systems
  • Test and measurement equipment
  • Precision rotary platforms
  • Medical imaging systems
Why Choose Our Slip Rings
  • Experienced manufacturer with professional engineering team
  • High precision manufacturing process
  • Strict quality control system
  • Custom slip ring solutions available
  • Fast technical support and global delivery
Frequently Asked Questions
What is a slip ring used for?

A slip ring is used to transmit power, signals, or data between stationary and rotating parts in rotating equipment such as robotics, radar systems, and industrial automation machinery.

What is the maximum speed of this slip ring?

This slip ring supports rotational speeds up to 3000 RPM, making it suitable for high-speed rotating applications.

What industries use slip rings?

Slip rings are widely used in industrial automation, robotics, UAV systems, radar antennas, medical equipment, and rotating cameras.

Can the slip ring be customized?

Yes, the slip ring can be customized with different circuits, current ratings, sizes, and protection levels depending on the application.
