Miniature Pancake Slip Ring 6 Circuits 2A Flat Disk Rotary Electrical Connector for Radar Antenna Platform

1 Piece
MOQ
USD 25-100 / Piece
Price
Miniature Pancake Slip Ring 6 Circuits 2A Flat Disk Rotary Electrical Connector for Radar Antenna Platform
Features Gallery Product Description Chat Now
Features
Specifications
Number Of Circuits: 6
Rated Current: 2A Per Circuit
Rated Voltage: 240V AC/DC
Dielectric Strength: ≥500V AC At 50Hz
Insulation Resistance: ≥500MΩ At 500VDC
Contact Material: Gold To Gold
Housing Material: Aluminum Alloy
Form Factor: Pancake Flat Disk
Overall Thickness: 15mm
Operating Speed: 0-200 Rpm
Operating Temperature: -40°C To +80°C
Protection Grade: IP54
Highlight:

Pancake Flat Disk Design

,

Gold-Gold Contact Technology

,

Low Profile Installation
Basic Infomation
Place of Origin: Guangdong, China
Brand Name: WNRLN
Certification: ISO 9001:2015, CE, RoHS
Model Number: MSR-6C-2A-PK
Payment & Shipping Terms
Packaging Details: WNRLN branded box with anti-static foam insert, export-grade corrugated carton
Delivery Time: 3-5 working days for stock, 15-25 days for production
Payment Terms: T/T, L/C, PayPal, Western Union
Supply Ability: 5000 Pieces per Month
Product Description

Miniature Pancake Slip Ring 6 Circuits 2A – Flat Disk Rotary Connector

Product Overview

The WNRLN MSR-6C-2A-PK Pancake Slip Ring adopts a flat disk form factor only 15mm thick, making it ideal for radar antenna platforms and height-restricted rotary installations. Six independent 2A circuits with gold-gold contacts deliver reliable power and signal transmission in an ultra-low-profile package.

Key Features

  • Pancake Flat Disk Design: Only 15mm overall thickness enables installation in tight vertical spaces.
  • Gold-Gold Contact Technology: Premium gold-plated disk contacts ensure consistent performance.
  • Low Profile Installation: Ideal for applications where height clearance is the critical constraint.
  • Large Center Bore: Disk form factor provides generous center opening for shaft mounting.

Technical Specifications

ParameterValue
Number of Circuits6
Rated Current2A per circuit
Rated Voltage240V AC/DC
Form FactorPancake Flat Disk
Overall Thickness15mm
Contact MaterialGold to Gold
Housing MaterialAluminum Alloy
Operating Speed0-200 rpm
Protection GradeIP54

Applications

  • Radar Antennas: Rotating antenna platforms with height constraints.
  • Satellite Dishes: Azimuth rotation power and LNB signal transmission.
  • Lazy Susans: Motorized rotating serving platforms.

Quality Assurance

  • ISO 9001:2015 certified manufacturing
  • CE and RoHS compliant
  • 100% flat contact alignment and continuity testing
