High Current Conductive Slip Ring 100A Per Circuit 4 Channel Silver Graphite Brush Heavy Duty Rotary Welding Joint

High Current Conductive Slip Ring CBSR-HC-100-4

The CBSR-HC-100-4 high current conductive slip ring is purpose-built for heavy-duty industrial applications requiring robust 100A power transmission per circuit. Utilizing premium silver graphite brush technology paired with silver-plated copper alloy conductor rings, this rotary joint delivers exceptional conductivity with contact resistance below 5mΩ and outstanding thermal management for continuous high-current operation.

Key Features

• 100A Per Circuit Rating — Four independent channels each capable of handling 100A continuous current at 600V AC/DC
• Silver Graphite Brush System — Self-lubricating silver graphite composite brushes ensure consistent low-resistance contact and superior heat dissipation
• Silver-Plated Copper Rings — High-conductivity copper alloy rings with thick silver plating for minimal voltage drop and extended wear life
• Heavy-Duty Steel Housing — Anti-corrosion coated steel enclosure with reinforced bearing assembly rated for 0-100 RPM continuous duty
• Wide Temperature Tolerance — Operational reliability from -20°C to +120°C, suitable for demanding industrial environments

Applications

Engineered for welding positioners, electroplating barrel drives, industrial cable reels, rotary kilns, coil winding machines, resistance welding turntables, and heavy automation equipment requiring high-amperage power transfer across rotating interfaces.
