Gigabit Ethernet Conductive Slip Ring CBSR-ETH-GE-8

The CBSR-ETH-GE-8 represents the next generation of integrated rotary joints, combining 8 independent 2A power circuits with a dedicated Gigabit Ethernet data channel in a single compact assembly. This advanced conductive slip ring enables simultaneous power delivery and high-speed 1000Mbps data transmission through a rotating interface, making it the perfect solution for modern IP-based surveillance, radar, and digital communication systems.

Key Features

• Gigabit Ethernet Data Channel — Dedicated RJ45 channel supports 10/100/1000 Base-T protocols with CAT6 compatibility for uninterrupted high-bandwidth data streaming
• 8 Integrated Power Circuits — Each power circuit rated at 2A/240V AC/DC, enabling simultaneous device powering alongside data transmission
• Low Signal Loss Design — Insertion loss ≤1.0dB and return loss ≥15dB ensure signal integrity across the rotating interface
• Gold-on-Gold Contact Technology — Premium contact material delivers consistent low-noise performance for both signal and power circuits
• FCC Certified — Meets electromagnetic compatibility standards for reliable operation in sensitive electronic environments

Applications

Designed for IP pan-tilt-zoom cameras, marine and ground radar antenna systems, digital signage rotating displays, robotic vision systems, remote weapon stations, and automated test equipment requiring combined high-speed data and power rotary transmission.
