Pancake Flat Conductive Slip Ring 15mm Thickness 8 Circuits 2A Ultra Thin Low Profile Rotary Joint Space Constrained Use

Pancake Flat Conductive Slip Ring CBSR-PK-15-8

The CBSR-PK-15-8 pancake conductive slip ring features an ultra-thin 15mm axial profile with 8 independent 2A circuits arranged on a flat disc architecture. This unique form factor solves the challenge of integrating rotating electrical connections into axially constrained spaces — where traditional drum-style slip rings simply cannot fit. Ideal for turntables, slim rotating displays, and compact automation assemblies.

Key Features

• 15mm Ultra-Thin Profile — Minimal axial thickness enables integration into flat rotating assemblies where vertical space is severely limited
• 150mm Outer Diameter Platform — Generous disc area provides stable 8-circuit layout with excellent circuit-to-circuit isolation on FR4 substrate
• 8 Gold-on-Gold Circuits — Flat ring and spring-loaded brush contact system delivers reliable 2A per circuit transmission with consistent low electrical noise
• Space-Saving Pancake Architecture — Flat disc design distributes circuits radially rather than axially, achieving thinness that traditional drum slip rings cannot match
• Customizable Form Factor — Center hole and outer diameter dimensions can be tailored to specific mechanical integration requirements

Applications

Specifically designed for rotating display turntables, compact CCTV dome rotation, thin-profile rotary index tables, lighting gimbals, exhibition display rotating platforms, small radar antenna pedestals, and any rotating equipment where axial height is more constrained than radial space.

Technical Specifications
