100000 RPM Ultra High Speed Micro Slip Ring 4 Circuits Air Bearing Design for Spindle Metrology

100000 RPM Ultra High Speed Micro Slip Ring 4 Circuits Air Bearing Design for Spindle Metrology

A 14 mm class micro slip ring designed for 100,000 rpm operation using an air bearing rotor to eliminate mechanical contact at the shaft. Four circuits carry sensor excitation and signal return for spindle error motion and thermal growth measurement in precision machine tool metrology.

Key Features

• Air bearing rotor removes mechanical contact at extreme speed
• 14 mm body fits inside spindle nose assemblies
• Sub 0.5 N.cm starting torque avoids disturbing spindle dynamics
• Four circuits for sensor excitation and signal return
• Balanced rotor minimises vibration above 50000 RPM
• Optional vacuum compatible materials for cleanroom spindles

Technical Specifications

Typical Applications

• Machine tool spindle metrology
• Ultra precision grinding spindles
• Turbo molecular pump instrumentation
• High speed dental and medical handpieces

Ordering Information

Model SP012014-U4 is available from one piece with carton packaging and delivery in one to three weeks. Custom circuit counts, lead wire lengths, connector terminations and mounting flanges can be quoted on request. Send your drawing or specification and our engineering team will confirm the matching configuration within two working days.
