High Current Conductive Slip Ring 50 Channel 60A Collector Ring with 50g Weight Rotary Joint Connector

1
MOQ
200~800 USD
Price
High Current Conductive Slip Ring 50 Channel 60A Collector Ring with 50g Weight Rotary Joint Connector
Features Gallery Product Description Chat Now
Features
Specifications
Rated Speed: 0-100 Rpm
Operating Env: -40~80℃, ≤80% RH
Insulation Resistance:: 500MΩ/500VDC
Rated V/I: 0-240VDC/Max 1A
Dielectric Strength: 500VAC/50Hz/60s
Dynamic Resistance Variation: 15mΩ
Highlight:

50 channel high current slip ring

,

60A collector ring rotary connector

,

lightweight 50g slip ring connector
Basic Infomation
Place of Origin: Shenzhen
Brand Name: SPR-ing
Model Number: SP013028
Payment & Shipping Terms
Packaging Details: Carton
Delivery Time: 1 week
Payment Terms: L/C,T/T
Supply Ability: 1000/month
Product Description
High Current Conductive Slip Ring 50 Channel 60A Collector Ring with 50g Weight Rotary Joint Connector
SP013028 high speed slip ring offers excellent conductivity and durability thanks to its gold-gold contact structure. The integrated casting process guarantees high concentricity, making it ideal for precision rotating equipment with limited installation space.
Technical Specifications
Electrical Specifications
Design Loop 26, 28, 50 (L=49.5)
Insulation Resistance 500MΩ/500V/DC
Rated Voltage/Current 0-240VDC / Max 1A
Dielectric Strength 500VAC/50Hz/60s
Dynamic Resistance Change Value ≤15mΩ
Mechanical Specifications
Rated Speed 0-100 rpm
Working Life 10 million rpm
Operating Temperature -40℃ to 80℃
Operating Humidity ≤80%
Contact Material Gold-gold
Shell Material 303 Stainless Steel
Maximum Starting Torque 1 N.cm
Weight <50g (not include wire)
Wire Specifications AFR250-0.05mm²
Outline Drawing
High Current Conductive Slip Ring 50 Channel 60A Collector Ring with 50g Weight Rotary Joint Connector 0
Technical Advantages
  • Gold-gold contact provides high conductivity, excellent thermal conductivity, low temperature coefficient of resistance, with resistance to sulfurization, oxidation, and corrosive gases, plus superior hardness and wear resistance with good resistance to welding, arc corrosion, and burns.
  • Integrated casting process ensures concentricity between ring groove and bearing ≤ 0.01mm.
  • Mirror processing technology achieves slip ring contact surface smoothness of Ra0.02 for more reliable contact.
  • Precision component manufacturing process with dimensional tolerance <0.01mm provides high precision and more stable contact.
  • Near-zero pressure electric brush design and debugging process extends slip ring life by 1/3.
  • Compact size and structure meets user space constraints.
